Online demonstrations and training available from Mecmesin technical sales engineers

April 2020:
Online test equipment and training demos



As more people are working from home to reduce non-essential travel, our technical sales engineers can provide online equipment demos or training sessions via web-based video calls.

If possible, send in your own samples and our sales team will be able to present your own products being tested.

Get in touch to discuss your requirements and to arrange an online demo or training session.

Mecmesin Emperor Force testing software displayed on Windows laptop

Emperor™ Force software

Easy-to-use software with almost limitless freedom to design and customise tension and compression tests to suit your needs. Developed by Mecmesin in close collaboration with our customers, Emperor is now trusted by over 5,000 companies for the detailed testing and evaluation of their products.

Create simple tests for the production line and more complex laboratory tests to prove design standards are met.

Freedom and support to meet your force testing needs

Easily create step-by-step test routines

Start measuring tensile & compressive forces to evaluate your products in just a few minutes by creating your own step-by-step test routines. We will help get you started and are always on hand to support you.

Unlimited user licenses

Every test system comes with a full and unlimited user licence for Emperor force testing software. There are no hidden extras or limitations - you get the full package.

Share data files easily around the world

Copy and install the software on any computer making it easier to share data files with colleagues around the world.

Key features

Create

Intuitive user interface

Build test routines step by step

Favourite one-touch tests

Test

Realtime graph plotting

Display measured and calculated values

Clear pass/fail indication

Report

Standard and customisable templates

Print results to Adobe PDF format

Export data to Excel and SPC packages

Trusted by over 5,000 customers worldwide

Emperor force testing software - labelled system components

Software control

Emperor Force testing software runs on any Windows computer. The software takes full control of the test frame motor whilst simultaneously collecting data from the ILC loadcell and displacement encoder.

Start your chosen routine from a PC or console and Emperor automates the complete test procedure.

Easy to use

Design and configure step-by-step test routines to match your testing procedures. An intuitive interface makes it easy to create, customise and save tests.

Consistently apply tensile or compressive force to the specimen up to a preset limit or until it breaks, stretch or crush the specimen to a certain displacement or cycle it several times to measure its performance.

Console mode for operators

Dedicated mode for the production line environment - designed for routine testing with minimal training. Launch with one touch of a favourite test icon.

To keep things really simple and secure you can even control individual operator access to specific tests and software functions.

Realtime results

Realtime results

Measurement data is displayed live on a graph as the test is running so that the user can see exactly how the specimen is performing.

Data from the ILC loadcell and displacement encoder is collected by Emperor force software at an impressive 1,000 times per second (1 kHz).

Pass or fail indicator

A clear pass (green) or fail (red) indication leaves an operator in no doubt about the status of each specimen, based on your test standards.

Report and analyse

A powerful reporting module allows you to configure test reports to present data the way your customer wants to see it.

The library of preset calculations makes analysing the data simple.

Share your data

All the test data can be exported to Microsoft Excel or for a statistical process control (SPC) package.

You can install copies of Emperor on other computers to share your customised test routines and results data.

We're here to help

Our technical engineers will help you get started and show you how to configure routines to your exact testing requirements.

We are always on hand to support you and if you need any advice or guidance after installation.



Speak to an expert

Got a question about a product? Request a call back from one of our Technical Sales Engineers now.



Supported products

MultiTest-iSingle-column force tester

PC-driven
MultiTest-i

The MultiTest-i is a versatile tensile and compression tester controlled by software running on a PC.

The single-column range fits neatly on your bench-top and is ideal for product testing applications according to your own test methods.

A wide range of tensile grips, bend jigs and compression fixtures make the single-column MultiTest-i easy to use for measuring tension and compression, from as little as 2 N right up to 5 kN.

MultiTest-i 2.5 kN automated force testing system
Console-driven
MultiTest-xt

The MultiTest-xt is a versatile tensile and compression tester controlled by software running on a touchscreen console.

The single-column range fits neatly on your bench-top and is ideal for product testing applications according to your own test methods.

A wide range of tensile grips, bend jigs and compression fixtures make the single-column MultiTest-xt easy to use for measuring tension and compression from as little as 2 N right up to 5 kN.

MultiTest-xt 2.5 kN automated force testing system, with operator console

The MultiTest-i is a versatile tensile and compression tester controlled by software running on a PC.

The single-column range fits neatly on your bench-top and is ideal for product testing applications according to your own test methods.

A wide range of tensile grips, bend jigs and compression fixtures make the MultiTest-i easy to use for measuring tension and compression, from as little as 2 N right up to 5 kN.

MultiTest-iTwin-column force tester

PC-driven
MultiTest-i

The MultiTest-i is a versatile tensile & compression tester controlled by software running on a PC. The twin-column range can be mounted neatly on your bench-top and is ideal for product testing applications according to your own test methods.

A wide range of tensile grips, bend jigs and compression fixtures make the MultiTest-i easy to use for measuring tension and compression from as little as 2 N right up to 50 kN.

Product image of MultiTest 25-i high capacity twin-column force testing system with PC
Console-driven
MultiTest-xt

The MultiTest-xt is a versatile tensile & compression tester controlled by a touchscreen console. The twin-column range can be mounted neatly on your bench-top and is ideal for product testing applications according to your own test methods.

A wide range of tensile grips, bend jigs and compression fixtures make the MultiTest-i easy to use for measuring tension and compression from as little as 2 N right up to 50 kN.

Product image of MultiTest 25-xt high capacity twin-column force testing system with integrated console

The MultiTest-i is a versatile tensile & compression tester controlled by software running on a PC. The twin-column range can be mounted neatly on your bench-top and is ideal for product testing applications according to your own test methods.

A wide range of tensile grips, bend jigs and compression fixtures make the MultiTest-i easy to use for measuring tension and compression from as little as 2 N right up to 50 kN.
